DESCRIPTION

Overview

Basic Info.

Model NO.	EPC-1
Contact	Normally Open
Brand	Monro
Certification	ISO9001, CE, TUV
G.W of Carton	18.5kgs
N.W of Carton	16.5kgs
Qty Per Carton	12PCS
Carton Size	53*47.5*38cm
Transport Package	Carton
Specification	169*167*228mm; nylon+ABS, copper rod
Trademark	MONRO
Origin	China
HS Code	9032810000
Production Capacity	200000/Month

Product Description

We strictly control the quality of products ensure the quality of each product,ensure that customers can receive the best products.Our Advantages

Product Description

HIGHLIGHT FEATURES:1.Simple installation, easy to operate2.Save the cost of water system installation3.Protect the pump, longer it's life

Product application:Widely used in a variety of peripheral pumps, self-priming pumps, jet pumps, centrifugual pumps, garden pumps and other water supply systems: Ordinary wells and tube wells, Household water booster, High buildings water booster, Irrigation system.Product Parameters

EPC-1 TECHNICAL PARAMETERS
Rated voltage	220-240V	110-120V	110-240V
Power Frequency	50/60HZ	50/60HZ	50/60HZ
Max using current	10A	10A	10A
Max power	1.1kW	0.55kW	0.55kW/ 1.1kW
Starting pressure setting	1.2bar; 1.5bar; 2.2bar	1.2bar; 1.5bar; 2.2bar	1.2bar; 1.5bar; 2.2bar
Max working pressure	10bar	10bar	10bar
Connection thread	G1''; G1 1/4''; G1 1/2''; NPT1''	G1''; G1 1/4''; G1 1/2''; NPT1''	G1'';G1 1/4''; G1 1/2''; NPT1''
Protection rating	IP65	IP65	IP65
Max working temperature	55ºC	55ºC	55ºC

Choice: The automatic control and the water pump

S. NO.	Automatic Controller's Starting Pressure	Min Water Pump Lift	Using Height
	X(bar)	L=10*(X+0.8)(m)	H≤ 10*X-2(m)
1	1.2	20	10
2	1.5	23	13
3	2.2	30	20

The data in this table take into account the situation that pump head will decrease after a period of use.
1.Relay: we use original OMRON relay.2.Plastic Parts: All is new material, no recycling; high strength reinforced polyamide.3.Diaphragm: EPDM diaphragm, don't have any smell.

Function:

1.Electric swith used in water systems,start and stop the pump automatically

2.Examine the water automatically,stop the pump in the case of water shortaget,protect the pump from damage caused by dry-running

3.Completely replaced traditional pump control system composed of pressure switch,pressure tank and check valve,etc.

·Auto Start/Stop
·Stop with Pressure keeping·Water Shortage Protection·Automatic restart in case of water failure ·Water pump impeller jammed protection·Pipeline leakage protection·Flow switch jammed protection Company Profile

ZHEJIANG MONRO MACHINERY&ELECTRONIC CO.,LTD is located in Wenling,Zhejiang province ,

which is a industrially development city with convenient transportation . With more than 20 years of production history for pressure controls and float switches. At present, our factory has more than30 various types of pressure control which used for water pump system and air compressor.

FAQ

Q: What's your MOQ? A: 204PCS per model for normal package
Q:Could do brand packing? A: EPC series, above 1200pcs; KRS series, above 3000pcs; FPS series, above 2000pcs
Q:How about the delivery time? A: 3-5days for samples; EPC series 180,000pcs/month; KRS series 250,000pcs/month; FPS series 40,000pcs/month
Q: How about warranty? A: 1 YEARQ:Do you have any certificates? A:ISO9001;TUV(Germany); CE(Europe);UL
